DIAMOND® 9D RETAINING WALL SYSTEM

DIAMOND® 9D RETAINING WALL SYSTEM

Description

The dependability of the Diamond® retaining wall system has made it the preferred choice for decades. The Diamond® 9D retaining wall blocks have the advantages of an easy-to-handle lighter weight and a beautifully distressed appearance.

diamondwall1.jpg3.jpg4s.jpg5.jpg6.jpg77

Product Uses

  • Curved Walls
  • Straight Walls
  • Terraced Walls
  • Steps
  • Corners
  • Planters
  • Raised Patios



System Performance

Maximum Gravity Wall Height: 3’0″
System Batter: 10.6°
Minimum Inside Radius: 6’0″
Minimum Outside Radius: 3’0″

Wall Units

Diamond® 9D

Dimensions

Height: 6”
Front Length: 17-3/4”
Depth: 9”

Weight: 52 lbs.
Coverage: 0.74 sq. ft.
Setback: 1-1/8”
